Machine Use Stretch Film
Machine-Use Stretch Film is a high-performance, precision-engineered stretch wrapping film specifically designed for use with automatic and semi-automatic stretch wrapping machines. Unlike hand-grade films, machine-use films are manufactured with tighter gauge tolerances, consistent unwind characteristics, and enhanced mechanical properties to withstand the demands of high-speed, high-volume pallet wrapping operations.
Detailed Introduction
Product name:
Machine use stretch film
Features:
1. Precision Gauge Control
Manufactured with strict thickness uniformity (±1–2 µm tolerance). Ensures consistent film tension, stretch percentage, and load containment across every pallet — eliminating weak spots and reducing film breaks during machine operation.
2. Optimized Unwind & Feed Characteristics
Engineered for smooth, chatter-free unwinding at high speeds (up to 120+ RPM). Reduced friction and static buildup ensure reliable feeding through pre-stretch carriages and film delivery systems.
3. High Pre-Stretch Capability
Designed to achieve 200% – 400% pre-stretch ratios depending on film grade. Maximizes film yield per pallet, reducing material consumption and cost per load.
4. Superior Load Containment
High holding force retains load integrity during transport and storage. Resists load shifting, collapse, and unit load failure even under vibration and shock conditions.
5. Consistent Cling Performance
Balanced cling formulation provides secure layer-to-layer adhesion without blocking or sticking to machine rollers. Clean release from film carriage.
6. Puncture & Tear Resistance
Reinforced with advanced polymer blends to resist sharp edges, corner protrusions, and irregular load profiles. Reduces downtime caused by film breakage.
Applications:
- Warehouse & Distribution Centers: High-volume pallet wrapping for retail, e-commerce, and wholesale goods.
- Manufacturing Plants: Securing raw materials, work-in-progress, and finished goods.
- Food & Beverage: Wrapping bottled goods, canned products, and case-packed items.
- Pharmaceutical & Chemical: Clean room compatible grades available.
- Building Materials: Wrapping bricks, tiles, lumber, and insulation panels.
- Automotive Parts: Securing heavy and irregularly shaped components.
Benefits:
- Reduced Film Consumption: Higher pre-stretch ratios mean less film per pallet — lower cost per load.
- Increased Throughput: Faster machine speeds and fewer film breaks maximize productivity.
- Consistent Quality: Precision manufacturing eliminates variability between rolls.
- Lower Downtime: Reliable performance reduces machine stoppages and operator intervention.
- Sustainable Operations: Less material usage translates to lower environmental footprint.
Specifications:
|
Width (mm) |
100/120/125/130/150/200/300/380/400/450/500/750 |
|
Length (m) |
100/200/300/400/500/600/700/800/900/1000/1100/1200/etc. |
|
Thickness (mic) |
8~35 |
|
Paper Core Dia (inch) |
1/1.5/2/3 |
|
Net weight (kg) |
0.4~43 |
|
Color |
Transparent/Black/Red/Orange/Blue/Green/Yellow/etc. |
*Availability to produce on request widths and characteristics different from standard.
Technical Specifications:
|
Thickness Range |
Tensile Strength(Longitudinal Lateral) |
Elongation at Break(Longitudinal Laterial) |
Angel Tear Stretch(Longitudinal Laterial ) |
Impact ability or Pendulum |
Tackiness |
Light Transmission Rate(Clear) |
Frong Density(clear film) |
|
Micron |
Mpa≥ |
%≥ |
N/mm≥ |
J≥ |
N/cm≥ |
%≥ |
%≥ |
|
15-17 |
37 |
250,500 |
120 |
0.14 |
3.0 |
93 |
2.4 |
|
18-20 |
38 |
300,600 |
120 |
0.15 |
3.0 |
92 |
2.5 |
|
21-25 |
39 |
300,600 |
120 |
0.17 |
3.0 |
91 |
2.6 |
|
26-30 |
40 |
400,650 |
120 |
0.19 |
3.0 |
90 |
2.7 |
|
31-35 |
41 |
450,700 |
120 |
0.21 |
3.0 |
89 |
2.8 |
